BTP30 ER Collet Chuck
AccuPlus™ BTP ER Collet Chuck
Available Options
| Cat. no. | Description | Collet Size | ØD Range (mm) | ØD1(mm) | L (mm) | J Adj. Screw | Coolant Style | Stock | Price | Quantity | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 872106020 | BTP30-CHE 11-100 | ER11 | 3-7 | 19 | 100 | M6X1 | AD Thru | ||||
| 872106112 | BTP30-CHE 16-60 | ER16 | 3-10 | 28 | 60 | M10X1.5 | AD Thru | ||||
| 872106120 | BTP30-CHE 16-100 | ER16 | 3-10 | 28 | 100 | M10X1.5 | AD Thru | ||||
| 872106212 | BTP30-CHE 20-60 | ER20 | 3-13 | 34 | 60 | M12X1.75 | AD Thru | ||||
| 872106221 | BTP30-CHE 20-105 | ER20 | 3-13 | 34 | 105 | M12X1.75 | AD Thru | ||||
| 872106312 | BTP30-CHE 25-60 | ER25 | 3-16 | 42 | 60 | M16X2.0 | AD Thru | ||||
| 872106320 | BTP30-CHE 25-100 | ER25 | 3-16 | 42 | 100 | M16X2.0 | AD Thru | ||||
| 872106412 | BTP30-CHE 32-60 | ER32 | 3-20 | 50 | 60 | M18X1.5 | AD Thru | ||||
| 872106420 | BTP30-CHE 32-100 | ER32 | 3-20 | 50 | 100 | M18X1.5 | AD Thru |
